“HIWIN” Robotic Gait Training System (Non-sterile) MRG-P110

Feature

HIWIN HEALTHCARE offers a wide range of medical robots based on its core technology of precision motion control. The robotic solutions are developed to assist medical practitioners in repetitive tasks and ease their daily burden, including rehabilitation robot. Our goal is to innovate from customer needs and participate in improving the quality of human life.

Robotic Gait Training System MRG-P110
Precision Step , Stable Rehab
  • • Quick Set Up: Improve the efficiency.
  • • 3-point Support: Remain clam, comfort and trust.
  • • Spasticity Detection: Keep the process safely.
  • • Smart feedback: Enhance motivation and participation.

Information
Specs Content
Dimensions 1785(L) x 1150(W) x 1425(H) mm
Weight 561kg
Power supply Single phase AC 220~240V, 50/60Hz , 5A
Space requirements 3000(L) x 2000(W) mm
Materials Steel, stainless steel, aluminum, rubber, plastic, wood, foam
Exoskeleton length Thigh length : 36cm~48cm
Calf length : 42cm~58cm
Maximal patient weight 135kg
Step length The maximal step length depends on the patient's thigh and calf length
Hip flexion: Minimum leg length 10~40cm / Maximum leg length 10~55cm
Body weight shifting: Minimum leg length 10~47cm / Maximum leg length 10~65cm
Knee control: Minimum leg length 10~58cm / Maximum leg length 10~80cm
Cadence 1~60steps/min
